ICDM-RX-EN1-4DB9-2RJ45-DIN

Comtrol ICDM-RX-EN1-4DB9-2RJ45-DIN
See any errors on this page?
Please let us know.

Alternative Views:
Pepperl+Fuchs Comtrol DeviceMaster 4 Port Serial Gateway, EtherNet/IP to Modbus w/(4) RS232/422/485 DB9M, (2) RJ45 10/100 & Screw Terminal Power (DIN Rail Mount)
Our Price: $813.00
Contact us for Partner Pricing. (more info)


Free Shipping
Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: ICDM-RX-EN1-4DB9-2RJ45-DIN

Description Technical Specs Drivers & Downloads

EtherNet/IP to Modbus Gateway 4-port DIN Rail Screw Terminal

The ICDM-RX/EN1 gateway enables the connection of serial devices (RS-232 / RS-422 / RS-485) such as barcode scanners, RFID readers and weigh scales to both EtherNet/IP and Modbus networks. It combines an EtherNet/IP interface with a Modbus gateway functionality and a built-in programmable data mapping sub-system, that ties everything together and doubles as a Modbus concentrator. The embedded web pages provide extensive diagnostics, intuitive and flexible configuration options, secure interfaces and numerous maintenance options. The result is a highly flexible gateway that allows full integration of EtherNet/IP controllers into simple or complex Modbus networks. EtherNet/IP controllers such as PLCs, HMIs, SCADAs and OPC servers can communicate to almost any Modbus master or slave, either locally or remotely.
Features
DIN-rail mounting and 4 DB9 serial connectors EtherNet/IP to Modbus TCP, Modbus TCP to EtherNet/IP, and Modbus to Modbus communications RS-232/422/485 software selectable interfaces Advanced Modbus gateway and routing capabilities Data Mapping sub-system and a built-in Modbus concentrator Web-based configuration NEMA TS2 Certified
